Practical guide
NFPA 101: coordinating egress and access control
What to assess before changing doors, locks or interfaces between access control and fire alarms.
An electronically controlled door provides asset security within a route that may be needed for evacuation. Before changing a lock or its programming, understand the room use, approved escape route and expected response to each condition.
Start with occupancy and the escape route
NFPA 101, Life Safety Code, is a reference for life safety and means of egress. Assessment must relate it to occupancy, building conditions and the applicable basis in Peru. A solution suitable for one door or use cannot be transferred to every door without evaluation.
Gather evacuation drawings, the role of each door, installed hardware, power sources, interfaces and the approved sequence. Identify who can authorise changes and who will validate the field result.
Four conditions the design should clarify
- Normal operation: authorised passage, exit and event recording.
- Emergency: intended response to a fire signal and other defined events.
- Power or communications loss: expected door assembly condition and supervision.
- Restoration: criteria for returning to normal without obstructing an exit or hiding a fault.
Document the interface without assuming a universal command
| Field | Evidence | Validation owner |
|---|---|---|
| Use and route | Drawing and the door’s role in the evacuation route. | Designer and building owner. |
| Hardware and power | Model, installation and manufacturer documentation. | Access control and electrical disciplines. |
| Emergency response | Approved sequence and authorised test result. | Fire, access control and operations owners. |
There is no basis for assuming all doors should open or close through a single command. The response depends on the door’s function, hardware, life safety strategy and approved design. A software indication alone does not confirm the physical state of the assembly.
Agree testing and follow-up
The intervention plan must provide safe access, contingencies and restoration. Emergency condition tests require a procedure and approval by the technical lead. At handover, retain the interface matrix, results by door, changes and limitations. An unassessed door remains outstanding even if the rest of the system responds correctly.
How BBS organises the work
- Initial assessmentInventory, fault history and criticality.
- Intervention planScope, permissions, owners, contingency and acceptance.
- Execution and testingChange control and verification of authorised interfaces.
- Handover and follow-upEvidence, validated results and outstanding actions.
Sources and scope
Public reference sources checked on 5 October 2026. This BBS guide provides planning recommendations; applicable editions and requirements must be validated for each project.
